Electric Forklift Truck SXV-CB 10
Flexibility meets innovation
- Load capacity 1000 kg
- Rated lift 5380 mm
- Speed 12 km/h
The SXV-CB is a reliable all-rounder for a range of applications. The electric forklift truck is extremely compact and particularly stable when cornering thanks to excellent weight distribution and automatic speed restriction. With its narrow aisle width and small turning radius, it is also extremely manoeuvrable in the tightest of spaces. It can effortlessly lift up to 1,000 kilograms on its cantilever forks. The SXV-CB is user-friendly, and, thanks to its speed-dependant steering, can be controlled with precision and efficiency with minimal effort. There is also the option of integrating a second control panel for added convenience when reversing. This facilitates forward and reverse driving with left- and right-handed operation, without having to turn your body too far.
Speaking of comfort: Drivers love the SXV-CB for its ergonomics, which guarantee fatigue-free load handling. This is ensured by the comfortable stand-on workplace which offers plenty of space to move, the upholstered backrest, the low step height of 120 mm on each side and the ergonomic steering and operation without needing to alter your hand position. The unrestricted view of the warehouse and load provide a high level of working comfort, as well as safety. After all, where the driver effortlessly has everything in view, driver, surroundings, load and vehicle are kept safe. The robust overhead guard also contributes to safety, while the optionally configurable warning light aids visibility in warehouse traffic. This means that the SXV-CB provides an answer to many common issues in warehouse management and is your powerful and versatile partner for stacking, transportation, order picking, or loading and unloading.
A versatile all-rounder:
compact dimensions, intuitive operation and outstanding availability ensure a high level of stability and therefore a wide range of potential applications
Manoeuvrability in confined spaces:
small turning radius and narrow aisle width
Ergonomic workplace:
comfortable driver’s seat and fatigue-free load handling thanks to speed-dependent steering without readjusting hand position
Request to: SXV-CB 10
Please fill out the form below. We will get back to you as soon as possible.
The "Simply Efficent" factors: Performance attributes as a measure of economic efficiency
Simply easy
Fatigue-free operation:
precise and smooth electrical steering unit
Unobstructed view when driving:
free view mast and centrally positioned tiller
Precise control in the narrowest spaces:
sensitive proportional valve control and optional creep speed function
Drive, steer and lift with just one hand:
ergonomic and intuitive operation for left and right handers
Simply powerful
Optimal utilisation of storage space:
high lift heights and residual load capacities
The right driving programme for all situations:
outstanding efficiency or maximum handling capacity thanks to ECO, BOOST or Blue-Q
Maximum handling capacity:
powerful, reliable and low-maintenance AC drive motor
Always ready for use:
li-ion battery with a capacity of between 300 Ah and 500 Ah and straightforward lateral battery change
Simply safe
OptiSpeed tiller
adjusts speed automatically depending on the distance between the operator and the truck
Safe cornering:
Curve Speed Control automatically adjusts speed to the steering angle when cornering
Simply flexible
For all pallet types:
adjustable forks enable handling of a wide range of pallets
For all load carriers:
thanks to the self-supporting forks, closed carriers can also be lifted with ease
Individually expandable:
up to two additional hydraulic functions for attachments
Simply connected
Manage online:
with FleetManager, you can link the forklift truck to a web-based application
Suitable for multiple operators:
define several forklift truck users with different operator profiles
All trucks under control:
fleets can be analysed based on need using comprehensive data
Information at a glance:
modern easy-to-follow colour display
STILL Li-Ion Technology inside
The perfectly harmonised power system for reducing operating costs and increased truck availability.
More about STILL Li-Ion Technology
Request to: SXV-CB 10
Please fill out the form below. We will get back to you as soon as possible.
| Model | Maximum capacity (kg) | Maximum lift height (mm) | Travel speed (km/h) | Battery voltage (V) |
|---|---|---|---|---|
| SXV-CB 10 | 1000 | 5380 | 12 | 24 |
Downloads
The document provided for download is the updated version of the operating instructions for the standard truck. It does not include descriptions of customer options (Customer Option). For a concrete truck, please request the respective specific manual according to the serial number and the year of production from the STILL spare parts service.
